DAP Audio AMP-104 4 Channel Headphone Amplifier headphone mixer D1536
| Article number: | D1536 |
| Delivery time: | On stock, delivery same day in the shop, next day in webbshop |
• Separate volume control
• 2x 4 outputs
• Road-proof housing
The AMP 104 is for expanding or generating headphones 4 channels. It has a 6.3 TRS stereo input and a RCA stereo input ook-which makes it convenience for multiple applications. All 4 outputs have their Own volume controls and the headphones can be connected at both sides of the AMP-104. This makes it possible to connect ook 8 headphones, All which will be operated in groups of 2 pcs.
Specifications
Frequency Response: 20Hz-20KHzInputs: 6,3 TRS jack, RCA
Outputs: 6.3 TRS Jack (8x)
Output impedance: 2x 50 Ohm
Output Power: 2 x 50mW @ 32ohm
Power supply: 18V AC (adapter included)
Dimensions: 53 x 158 x 135 mm (HxWxD)
Weight: 0.72 Kg
